HGILD1OTR LED tri-color light source
HGILD1OTR LED tri-color light source
HGILD1OTR LED tri-color light source features
★ The light source appears three colors, respectively red, blue, green, white is three-color synthetic light;
★ Equipped with controller, no debugging, direct use, simple, convenient;
★ The color of light source can be controlled by computer or controller;
★ Light intensity can be adjusted;
★ Annular uniform light source.
實物拍攝
PGF500-80-1 500 focal length parallel light tube
PGF500-80-1 500 focal length parallel light tube
Main technical parameters
(1) Focal length of objective lens (theoretical value) F= 500mm
(2) Effective aperture: φ 80mm
(3) Field of view: 3°20 '
(4) Lighting bulb: 6V LED
(5) Resolution: 1.8"
(6) Overall size: 570× φ 90mm
(7) Weight: about 0.6kg
Instrument use:
Parallel light tube is obtained through it from the infinite distance of parallel light beam, this light beam is called parallel light. It is an important tool for assembling and adjusting optical instruments, and also an important part of optical measuring instruments. With different demarcation plates, micrometer lenses, or microscope systems, it is possible to measure the focal length, discrimination, and other imaging qualities of the lens group. The attached adjusted plane reflector is fixed on the workpiece with the moving straight line, and the moving workpiece can be checked by observing through the Gaussian eyepiece on the light tube with the Gaussian autocollimation lens attached to the light tube.
Working principle:
Figure 1 shows the working principle of pgF500-80-1 parallel optical tube. The cross partition board 2, which serves as the inspection reference target, is uniformly illuminated by light source 1. If the cross splitter 2 is located exactly in the focal plane of objective 3, then the light passing through the cross splitter 2 is refracted by objective 3 as a parallel beam, which is also equivalent to the beam from the target at infinity.
1. Light source component 2. Differentiation plate 3
平行光管外形結構和尺寸圖/Construction and dimensions
產品實拍/The product will
Diffuse reflector plate Diffuse device Standard whiteboard gray plate target PTFE
Diffuse reflector plate Diffuse device Standard whiteboard gray plate target PTFE
Various shapes of PTFE diffused in optical instruments are important accessories of integrating spheres
Application: calibration whiteboard, diffuse reflector, scattering plate, optical attenuator, laser concentrator, optical collector, integrating sphere, etc
Wavelength used: 250-2500 nm
Reflectivity: 97-99% (visible light)
Geometry: different shapes according to requirements
HGISLA300C98N001 Integrating sphere
HGISLA300C98N001 Integrating sphere
Product information
The light source can simulate the night sky light environment, starlight and moonlight environment, and provide weak light with stable color temperature and uniform illumination for scientific experimental research.
Main performance indexes:
1. Integrating ball diameter 300MM, light outlet 80MM;
2. Spectral range: 300-2500NM; Color temperature of light source 2856K ± 50K;
3. The illumination uniformity of light outlet is better than 95%;
4. The illuminance of the integrating sphere is continuously adjustable through the electric diaphragm, and the adjustable range is 0 ~ 102LX (illumination at the ball wall); Adjustable illuminance accuracy 0001LX; Both light sources are equipped with diaphragm, and the illumination can be adjusted in a large range.
5. Controller communication interface: 232 serial port communication.
6. Total weight of equipment: About 10kg.
