Optical electric lifting table high precision electronic control displacement table optical mechanical laboratory slide table micro adjustment table
Optical electric lifting table high precision electronic control displacement table optical mechanical laboratory slide table micro adjustment table
The product description
HGVA315 electric lifting platform can provide lifting movement, small volume, high precision, suitable for the occasion of height adjustment. It can also be used to achieve fine tuning movement under a microscope.
Product features
1, the use of stepping motor drive, realize the lifting displacement automatic adjustment, automatic control;
2, high precision precision grinding screw drive, with power self-locking function;
3, using steering mechanism, save space;
4, precision cross roller guide rail, high precision and stable operation;
5. The motor is placed vertically and laterally, with compact shape and stable operation;
6, the upper and lower limit switch effectively protect the product, photoelectric switch as zero, high precision;
7, servo motor can be equipped; Faster and more accurate.
Product technical parameters
Product outline dimension drawing
Physical product drawing
HGVM06 series manual screw lifting platform
HGVM06 series manual screw lifting platform
HGVM0610 product features
Super small volume design, saving space, easy to operate;
Precision thread drive, spring return, eliminate empty return;
★ A variety of supporting products, can be combined with HGMB5/MB7 base plate, HGTMO2213/HGTM04225 translation platform, HGIM0503 biaxial tilt platform, etc.
HGVM0605 features
Super small volume design, saving space;
Precision thread drive, spring return, eliminate empty return;
★ Can be connected to HGIM0405 biaxial tilt table and HGTM01113 or HGTM02113 translation table, combined into a multi-dimensional adjustment table.
產品參數
產品尺寸
產品實拍
HGVM05 series manual precision lifting platform
HGVM05 series manual precision lifting platform
Product features
● Internal wedge structure, the minimum scale and sensitivity is doubled;
● High precision cross roller guide rail, high precision, large load bearing;
● Micrometer head drive, quantitative reading, horizontal and vertical displacement distance is 2:1.
Product features
Differential lifting platform products are mainly used for lifting and adjusting objects. Large load, high precision, good stability, beautiful appearance, convenient for you to choose. Special requirements can be customized.
Product parameters
產品圖片
HGRA145Miniature electric rotary table
HGRA145Miniature electric rotary table
Product features
The table top is 45mm in diameter, small and flexible and easy to use; The standard is equipped with stepping motor and standard RS232 interface, which can increase photoelectric zero position, and can realize automatic control with HGC series motion controller; The rotating shaft system is made of bearing steel, with high matching precision, large bearing capacity and long service life; The transmission adopts worm gear structure, and the table can rotate forward and backward freely; The worm gear and worm are precisely matched, with comfortable movement and minimal air return; Mesa stop design, mesa center coincides with rotation center, and positioning center coincides with rotation center, which is convenient for positioning; Stepper motor and worm are connected by imported high-quality elastic coupling, with synchronous transmission and low noise; The outer ring of the table surface is marked with a ruler by a laser marking machine, and the marking line is clear and accurate, which is convenient for reading and initial positioning; Replaceable servo motor, suitable for industrial application.
HGIM0602 Double shaft manual tilting table
HGIM0602 Double shaft manual tilting table
Product features:
1. Provide two dimensional tilt adjustment for pitch and horizontal rotation;
2. Fine tooth screw drive, copper nut locking screw, compact structure, easy to operate;
3. High quality tension spring reset.
產品圖片
Two axis electric displacement heavy duty slide table microscope module precision XY double axis manual translation table two dimensional table
Two axis electric displacement heavy duty slide table microscope module precision XY double axis manual translation table two dimensional table
產品簡介及用途/Product use
HGWA01 series integral two-dimension electric translation table can realize two-dimension translation adjustment operation under the microscope. It can also be used in situations where space is limited and two dimensional adjustments are required.
產品特點/Product features
1, two dimensional integral design, compact structure, high accuracy of two axis orthogonal;
2, high quality ball screw drive, high repeat positioning accuracy, smooth operation, large driving force;
3, high quality elastic coupling connection, transmission synchronization noise is small;
4, both ends of the zero and limit switch, convenient accurate positioning and protection of the product;
5, the center square hole design, suitable for light, can be installed carrying glass;
6, the bottom has standard hole pitch threaded hole and through hole, convenient installation.
產品參數/Product parameters
產品尺寸圖/Size：
產品實拍/Product photos
