HGTA0725-0725P Precision slow electric translation platform
HGTA0725-0725P Precision slow electric translation platform
Product features
1, equipped with stepper motor and standard DB9 interface, with HGC series motion controller can achieve automatic control;
2, fine grinding screw drive, pitch 0.5mm, high resolution;
3, imported ultra-thin linear slide track, to ensure high precision of movement, thinner overall;
4, step motor or reducer and grinding screw through high quality elastic coupling connection, transmission synchronization noise is small;
5, both ends of the zero and limit switch, convenient accurate positioning and protection of the product;
6, equipped with handwheel, convenient debugging;
7, the bottom has a standard hole pitch through hole, convenient installation, the table has a standard hole pitch threaded hole, convenient installation equipment.
Product introduction and usage
Hgta0725-0725p electric translation platform to achieve translation adjustment operation, small size, can also be used in the space limited need for precise adjustment occasions, 0725P is equipped with a reduction mechanism, can achieve rapid adjustment.
Basic product parameters
尺寸圖/Size chart
產品接口定義/Product Interface Definition
產品實拍/The product will
HGTA01 series precision electric translation platform
HGTA01 series precision electric translation platform
Product features
1, equipped with stepper motor and standard DB9 interface, with HGC series motion controller can achieve automatic control;
2, imported high-quality ball screw drive, high repeatable positioning accuracy, long life;
3, precision linear bearing guide rail, comfortable movement, good vertical use effect;
4, the stepper motor and ball screw are connected by high-quality elastic coupling, the transmission synchronization noise is small, the matching control system of our company can be selected to achieve high resolution control;
5, the motor adopts double shaft, equipped with handwheel, easy to debug;
6, both ends are equipped with zero and limit switch, convenient and accurate positioning, special instructions can be installed mechanical limit;
7, using standard mounting hole, convenient combination;
8, replaceable servo motor, high speed, high precision, high load operation occasions.
Product introduction and usage
This product is mainly used for the object translation movement, including horizontal translation and vertical translation, through different control procedures to achieve horizontal and vertical reciprocating movement, intermittent movement, micro processing and teaching demonstration. It can be used as auxiliary equipment for research and experiment in optics, kinematics, vibration, mechanics and other fields in laboratories and colleges in various fields.
產品技術參數/Product technical parameters
產品尺寸/Product size
尺寸說明/Size specification
產品實拍/The product will
HGIM0103A Manual single axis tilt table
HGIM0103A Manual single axis tilt table
產品特點/Product features
Can provide single shaft precision adjustment; High quality spring reset to ensure the stability of adjustment; Equipped with precision locking handwheel to prevent misoperation; The mesa bottom plate is evenly reserved with threaded holes for easy installation. Special requirements are subject to customization.
產品參數/Product parameters：
| 俯仰范圍/Pitch range | ±3° |
| 臺面尺寸/Table size | 170*80mm |
| 負載/Load | 3kg |
| 自重/Weight of | 0.4kg |
| 手輪/The handwheel | 可鎖緊/Can lock |
產品尺寸/Product size
產品實拍/The product will
HGVA985 precision electric lifting platform
HGVA985 precision electric lifting platform
Product features
1. The working table is placed horizontally, the driving force is in the center of the table, and the four guide rails around are positioned to solve the problem of partial load caused by vertical use of the translation table, and the stability is naturally superior;
2, imported high-quality ball screw drive, repeat positioning accuracy, long life;
3, fine grinding worm gear pair drive, large load bearing, subdivision adjustment, self-locking function;
4, the guide rail is linear bearing guide rail, high precision, large load bearing, lifting quantitative adjustment;
5, the base has standard hole pitch through hole, convenient installation;
6, can be installed organ cloth dust cover, effective dust, beautiful and generous.
| 產品型號 | HGVA985 |
| 行程 | 85mm |
| 絲杠導程 | 5mm |
| 傳動比 | 180:1 |
| 軟件控制“螺距”輸入 | 0.028mm |
| 控制軟件“細分數”輸入 | 3200 |
| 重復定位精度 | 0.05mm |
| 電機（標配） | 42 步進電機（1.8°） |
| 額定工作電流 | 1.7A |
| 中心負載 | 100kg |
| 自重 | 17kg |
產品簡介及用途
HGVA985 電動升降臺為山東云科 HGVM985 手動升降臺電動款，是一款高分辨 率大負載、短行程精密升降機構。可以用來對光路裝置進行調整，也可作為激光 干涉測量裝置。是山東云科自主設計研發生產的一款性價比優越的升降裝置。該 系列有多種行程可供選擇，特殊需求接受定制。
產品實拍
相關產品
HGTM01 series manual side drive translation platform
HGTM01 series manual side drive translation platform
Features of precision manual side drive translation platform:
☆ The guide rail is precision cross roller guide rail, higher precision, large load bearing, long life;
☆ Displacement adjustment with small shape of the same stroke micrometer head;
☆ The use of spring return, eliminate the axial clearance;
☆ Compared with the basic model thinner thickness, lighter weight;
☆ The locking adopts a separate hand wheel on the side, which is not easy to scratch the surface and the locking is more firm;
☆ Mounting holes with standard pitch on the table and base for easy installation and combination:
☆ Can be composed of multi-dimensional adjustment frame with other series of displacement table.
產品實拍
HGTA11TW series bidirectional electric translation platform
HGTA11TW series bidirectional electric translation platform
Product features
● Equipped with stepper motor and standard DB9 interface, with HGC series motion controller can achieve automatic control, in-phase movement or reverse movement;
● Imported high-quality ball screw drive, repeat positioning precision, long life;
● Precision linear bearing guide rail, comfortable movement, good vertical use effect;
● Stepper motor and ball screw through high quality elastic coupling connection, transmission synchronization noise is small, optional our company supporting control system, to achieve high resolution control;
● Motor adopts double shaft, equipped with handwheel, easy to debug;
● Both ends are equipped with zero and limit switches, convenient and accurate positioning, special occasions can be equipped with grating ruler, accurate display of relative and absolute position;
● Equipped with the installation of right Angle block, available M6X10 hexagonal cylindrical head screw direct installation use, at the same time equipped with special-shaped T nuts, can also be directly fixed from below, the movement direction of the installation distance is adjustable;
● One base integrated guide rail two-way movement, unified benchmark, more stable movement, higher repeatability;
● Replaceable servo motor, high speed, high precision, high load operation occasions.
Product features
This product is mainly used for the object translation movement, including horizontal translation and vertical translation, through different control procedures to achieve horizontal and vertical
Complex movement, intermittent movement, micro-processing and teaching demonstration. Especially suitable for bidirectional laser positioning, device dispensing and other special applications.
產品實拍
