HGRA1 series turbine electric rotary table

Product features:

1. Standard equipped with stepper motor and standard RS232 interface, can increase the photoelectric zero, with HGC series motion controller can achieve automatic control;

2. The rotating shafting is made of bearing steel, with high precision, large bearing capacity and long service life;

3. Worm wheel and worm structure is adopted for transmission, and the table can be rotated freely;

4. The worm wheel and worm are carefully grinded and matched to make the movement comfortable and the air return is very small;

5. Cleverly designed clearance elimination structure can adjust the clearance caused by long-term use;

6. The diameter of the center through hole is limited by tolerance, and the center of the through hole coincides with the rotating center for convenient positioning;

7. Stepper motor and worm are connected by imported high-quality elastic coupling, synchronous transmission and low noise;

8. The outer ring of the table is a scale ring, and the circle can rotate relative to the table to facilitate reading and initial positioning;

9. Replaceable servo motor, suitable for industrial applications.

產品技術參數：

產品型號	HGRA145	HGRA160	HGRA1100	HGRA1200	HGRA1400
臺面直徑（mm）	45	60	100	200	400
傳動比	90;1		180;1		720;1
重復定位精度	＜0.01°		＜0.005°		＜0.003°
標配電機	42步進電機（1.8°）			57步進電機（1.8°）
最大靜轉矩	0.4Nm			1.2Nm
定額工作電流	1.7A			2.8A
最大速度	50°/sec		25°/sec		5°/sec
分辨率（8細分）	0.0025°		0.00125°		0.0003125°
中心通孔直徑（mm）	φ8.5+0.025	無	φ46+0.025	φ90+0.025	無
標配零位	無	無	有	有	無
中心最大負載	15kg	30kg	50kg	60kg	80kg
自重	0.65kg	1kg	1.54kg	7.7kg	19.75kg

產品實拍

未標題-2_01.jpg 未標題-2_02.jpg

可配我是運動控制器使用！

HGIM250 biaxial tilt table

Provide biaxial tilt adjustment;

★M8X0.5 fine tooth screw drive, high quality spring reset, large adjustment Angle, good stability;

★ Point, line and surface structure design, stable, good repeatability;

★ Installation mode: can be directly placed and used or four M6 screws with countersunk hole conversion installation;

★ It is suitable for the large size load which needs 2-d fine tuning. The four mounting holes can be connected to the support rod or plate parts of our company, and the whole is fixed on the optical platform for precise adjustment.

產品圖片

尾頁_01.jpg 尾頁_02.jpg 尾頁_03.jpg 尾頁_04.jpg

HGVM0 series manual shear lifting platform

Product features

★ Used for large stroke, non-quantitative, large load lifting adjustment;

★ Adopt scissor lifting support, fine grinding screw drive, double guide rail and five axis over positioning mechanism, ensure smooth and comfortable movement, high precision, large load bearing;

★ The upper and lower sides of porous design, strong applicability, can be used as mounting surface;

產品參數

產品型號	HGVM0160	HGVM0160R	HGVM02120
行程	60mm	60mm	120mm
靈敏度	0.01mm	0.01mm	0.01mm
臺面尺寸	80*120mm	80*120mm	140*220mm
負載	20kg	20kg	25kg
自重	1.15kg	1.15kg	3.5kg
標尺	無	有
