HGMMT104 dry plate rack fixture
HGMMT104 dry plate rack fixture
Product features
★ Used in holography and other optical experiments to install card plate, film, etc.
The inner layer with elastic top block fixed rigid thick dry plate;
★ The thin film is held by spring sheet in the outer layer, which is convenient for dark room operation.
Adjustable card width, strong versatility.
產品實拍
HGMM1 series V frame
HGMM1 series V frame
Product features
1, can be pressed from 6.6mm ~ 52mm (HGMM1160),50mm~100mm (HGMM11100) cylindrical objects;
2. The installation positions of the three M4 screw holes at the bottom can be changed;
3, four M6 countersunk head holes, optional fixed on the platform;
4. Each mounting seat is equipped with a pressure arm.
產品參數
| 型號 | 裝卡直徑（mm） | 自重（g） |
| HGMM11100 | 50~100 | 800 |
| HGMM1160 | 6.6~52 | 300 |
產品實拍
HGMPR1 series optical support rods
HGMPR1 series optical support rods
Product features:
● High quality aluminum profile body, profile internal reinforcement design strength, light weight;
● Large length, continuously adjustable height, large adjustment range;
● With HGMPC1 series supporting rod fixture, can support a variety of items;
● Unlimited circumferential position, 360 degrees free rotation direction;
● Unique cover plate design, prevent the release of small load at the same time can be installed.
產品實拍
HGMPR2 series optical rack and gear support bar
HGMPR2 series optical rack and gear support bar
Product features
● Thick diameter, good rigidity, large bearing capacity;
● Large length, continuous adjustable height, large adjustment range;
● Reasonable hardweight ratio design, good vibration resistance;
● With HGMPC2 support rod gear fixture, can support a variety of items;
● Rack and pinion matching, comfortable adjustment, high precision;
● The circular base can be removed and directly connected with the bottom plate using the M6 screw below.
產品實拍
HGMMP2254 two-dimensional polarizing mirror frame
HGMMP2254 two-dimensional polarizing mirror frame
Product features
1, can be installed clamping 1in (25.4mm) polarizing lens, pressure ring locked;
2, adopt precision shafting rotation adjustment, stable and reliable positioning;
3, the circumference of 360° engraving, convenient reading;
4, M6X0.25 fine tooth screw adjustment, high quality disc spring reset, elastic adjustable, until rigid.
產品參數
| 產品型號 | HGMMP2254 |
| 旋轉調整范圍 | 360° |
| 旋轉最小讀數 | 2° |
| 傾斜調整方式 | 螺紋副 |
| 傾斜調整范圍 | ±3° |
| 自重 | 0.15kg |
產品實拍
HGMSA series reducer screws
HGMSA series reducer screws
A small product is a great craftsman
★HGMSA568 variable diameter screw, a small universal platform on a rod;
Convenient M8 male thread and M6 female thread two-way conversion, and has a mounting hole, can be used as a conversion installation platform, can be used as a laser, CCD camera, optical fiber, lens frame and other optical instrument installation platform support;
★ Keep improving, twice the result with half the effort.
產品圖片
