HGMB series optical baseplate
HGMB series optical baseplate
Product features:
HGMB series baseplate is used to install and fix the adjusting frame on the workbench surface or combine various adjusting frame, which can meet any application that needs to connect and fix and transfer;
★ Various specifications, flexible selection, surface standard thread aperture, hole distance, strong versatility, can achieve a variety of uses, installation, fixing, transfer convenient and flexible.
HGMC series adjustable press plate
HGMC series adjustable press plate
Product features:
HGMC series press plate can fix the base plate, rod frame or adjusting frame and other light fixtures in any position of the table, not limited by the standard screw hole, convenient and flexible to use.
HGEAS series electric double opening slit
HGEAS series electric double opening slit
產品特點/Product features
● Equipped with stepper motor and standard DB9 interface, with HGC3 series motion controller can achieve automatic control;
● Fine grinding screw drive, high repeatable positioning accuracy, long service life;
● Double precision linear guide rail, comfortable and stable operation;
● Both ends are equipped with limits, accurate positioning;
● Installation mode: horizontal (optional right-angle installation block) vertical;
● Halogen tungsten lamp can be installed to adjust the light source for integrating sphere.
產品參數/Product parameters
本產品即是一款獨立的電動雙開啟狹縫，又是積分球?qū)Ｓ名u鎢燈光源調整配套裝置，安裝方式靈活，該款最大開口直徑φ50、40mm，中間移動過程為狹縫形式。特殊規格接受定制。
本產品即是一款獨立的電動雙開啟狹縫，又是積分球?qū)Ｓ名u鎢燈光源調整配套裝置，安裝方式靈活，該款最大開口直徑φ50、40mm，中間移動過程為狹縫形式。特殊規格接受定制。
產品尺寸/Product size
產品說明/The product description
實物拍攝/photo
相關產品/Related products
HGMOB series magnetic lift light holder
HGMOB series magnetic lift light holder
產品特點/Product features
Flexible installation: 4 M6x8 screws can be installed on the optical platform or other equipment, the magnetic force of the base can be adsorbed on the magnetic equipment, or can be directly placed on the desktop by its own gravity;
Flexible use: a variety of combinations to achieve different heights of use;
Rod frame and active support rod are engraved with ruler, lifting height and rotation Angle can be read, to achieve quantization.
尺寸圖/Size chart
選型表/Selection table
產品說明/The product description
實物拍攝/photo
相關產品/Related products
HGEMD series electric adjustable diaphragm
HGEMD series electric adjustable diaphragm
1, small size, light weight, reserved mounting holes, threaded holes and standard hole spacing, vertical installation, horizontal installation, flexible choice, but also can be used with our company's own production of integrating ball and light source, the overall versatility;
2, 20 (28) stepper motor and refined transmission structure, small air return, two-way precise limit;
3, excellent workmanship, durable;
4, continuous adjustable aperture;
產品參數/Product parameters
| 型號 | HGEMD20 | HGEMD52 | HGEMD60 |
| 孔徑 | 1.3mm-20mm | 3mm-52mm | 8mm-60mm |
| 調節精度 | ±0.05mm | ±0.1mm | ±0.1mm |
| 重復定位精度 | ±0.02mm | ±0.02mm | ±0.02mm |
| 標配電機 | 20 步進電機 | 28 步進電機 | 28 步進電機 |
| 最大調節速度 | 4mm/s | ||
| 控制方式 | 單片機 | ||
| 低調節范圍精度 | ±0.1mm（0.8-2mm） | ±0.2mm（3-4mm） | ±0.3mm |
產品尺寸/Product size
產品說明/The product description
產品實拍/The product will
相關配套產品/Related supporting products
MD series manual adjustable diaphragm
MD series manual adjustable diaphragm
產品特點/Product features
☆ In optical experiments, it is often necessary to use a point light source or control the amount of light, which can be realized by using a continuously adjustable aperture aperture. HGMD series adjustable diaphragm has many blades, smooth aperture, continuous adjustable, compact and beautiful appearance, and very convenient to use.
光闌尺寸選型表/Size selection table
型號 | 通光孔徑 | 外徑 | 厚度 （mm） | 葉片數 | 材 料 | 安裝方式 | 閉合控制方式 | ||
Φmax | Φmin | 內環 | 外環（殼） | ||||||
HGMD1068 | 6.8 | 0.8 | 22.5 | 4.5 | 6 | 銅 | 銅 | 配HGMDM1068光闌座 | 手柄 |
HGMD1075 | 7.5 | 0.8 | 14 | 5 | 8 | 銅 | 銅 | 配HGMDM1075光闌座 | 手柄 |
HGMD110 | 10 | 1 | 20 | 5 | 9 | 鋁 | 鋁 | 配HGMDM110光闌座 | 手柄 |
HGMD112 | 12 | 1 | 20 | 5 | 10 | 鋁 | 鋁 | 配HGMDM112光闌座 | 手柄 |
HGMD114 | 14 | 1.2 | 25.5 | 5.5 | 10 | 鋁 | 鋁 | 配HGMDM114光闌座 | 手柄 |
HGMD118 | 18 | 1.2 | 28 | 5 | 12 | 銅 | 銅 | 配HGMDM118光闌座 | 手柄 |
HGMD122 | 22 | 1.2 | 36 | 6 | 10 | 鋁 | 鋁 | 配HGMDM122光闌座 | 手柄 |
HGMD128 | 28 | 2 | 49 | 7.5 | 12 | 鋼 | 鋁 | 配HGMDM128光闌座 | 扁手柄 |
HGMD136 | 36 | 1.8 | 50 | 6 | 16 | 鋁 | 鋁 | 配HGMDM136光闌座 | 手柄 |
HGMD142 | 42 | 2.5 | 58 | 6.5 | 18 | 鋁 | 鋁 | 配HGMDM142光闌座 | 手柄 |
HGMD152 | 52 | 3 | 73 | 8 | 14 | 鋁 | 鋁 | 配HGMDM152光闌座 | 手柄 |
HGMD159 | 59 | 9 | 78 | 12 | 20 | 鋁 | 鋁 | 配HGMDM159光闌座 | 手柄 |
HGMD160R | 60 | 4 | 82 | 8 | 18 | 鋁 | 鋁 | 配HGMDM160光闌座 | 右手柄 |
HGMD160L | 60 | 4 | 82 | 8 | 18 | 鋁 | 鋁 | 配HGMDM160光闌座 | 左手柄 |
HGMD180 | 80 | 8.5 | 105 | 12 | 20 | 鋁 | 鋁 | 配HGMDM180光闌座 | 手柄 |
HGMD220 | 20 | 1 | 45 | 6 | 10 | 鋁 | 鋁 | 側椎扣（Φ23,L=3）＋陽螺紋圈(M30×0.5,L=6 | 外環 |
HGMD320 | 20 | 1 | 45 | 6 | 10 | 鋁 | 鋁 | 側椎臺（Φ23,L=3） | 外環 |
HGMD228 | 28 | 2 | 49 | 8 | 12 | 鋼 | 鋁 | 陽螺紋扣（M34×0.5,L=4） | 外環 |
HGMD230 | 30 | 1.6 | 50.5 | 8 | 12 | 鋁 | 鋁 | 陽螺紋扣（M35×0.5,L=4） | 外環 |
HGMD252 | 52 | 3 | 78 | 13 | 14 | 鋁 | 鋁 | 陽螺紋扣（M58×0.5,L=5） | 手柄 |
HGMD428 | 28 | 2 | 49 | 8 | 12 | 鋼 | 鋁 | 螺紋臺（M34×0.5,L=4） | 扁手柄調節，濾光片卡具 |
HGMD111P8 | 11.8 | 0 | 23.3 | 3.5 | 6 | 鋁 | 鋁 | 配HGMDM111P8光闌座 | 手柄 |
